Info 1/22: Supermini Face Clamping Kit (1,5 MB)

Kit with three clamping elements for different insert sizes, High rigidity of the entire system due to clamping wedge on insert face, Inserts can be changed without removing the holder

Download

Info 6/22: NEW HORN COATING RC2 / RC4 (2,5 MB)

High toughness and hardness allows milling at high cutting speeds, High temperature stability especially during dry machining, In-house production, Greenline ordering

Download

Info 7/22: GEAR SKIVING (1,5 MB)

Carbide skiving tool up to diameter of 120 mm, Holder adjustable to machining conditions, Switchable cooling systems for high process reliability

Download

Info 9/22: MODULAR HOLDER SYSTEM 850 FOR SCHÜTTE MULTI-SPINDLE AUTO (3,2 MB)

Suitable for the series ECX, SCX, ACX, Simple and easily accessible height adjustment, Targeted cooling on flank and rake face

Download

Info 10/22: NEW TOOLHOLDER FOR SYSTEM S224 (1,5 MB)

Quick insert change due to side clamping, Designed for use on Swiss-type lathes, Less machine downtime

Download

Info 11/22: NEW CUTTING GEOMETRY FOR MILLING SYSTEMS 406 AND 409 (1,6 MB)

Optimised insert geometry, Polished chipbreaker, Special grade for cutting group N

Download

Info 12/22: NEW GRADE FOR THE DAH8 HIGH-FEED MILLING SYSTEM (2,3 MB)

An extended range of grades, Indexable insert with carbide grade specially matched to the application, including coating, Precision sintered insert with 8 usable cutting edges

Download

Info 13/22: M475 GROOVE AND CUT-OFF MILLING SYSTEM (1,6 MB)

Higher efficiency due to larger number of effective cutting edges, Positive insert geometry with new grade, Neutral inserts for easy handling

Download

Info 14/22: PCD MULTI-TOOTH CUTTER (2,3 MB)

Highly economical finishing, Large number of effective cutting edges per diameter, µm-accurate axial run-out adjustment

Download

Info 15/22: NEW CHIPBREAKING GEOMETRY FOR 108 MINI SYSTEM (2 MB)

I-geometry for internal copy, longitudinal and face turning, Good chip control in steel, stainless steel and non-ferrous lead-free metals, Corner radii 0.05 to 0.20 mm

Download
